Waukesha 7042G Non-Turbo Overhaul Rebuild Kit
Waukesha 7042G Non-Turbo Overhaul Rebuild Kit - Image 2

Waukesha 7042G Non-Turbo Overhaul Rebuild Kit

Original price was: $97,847.24.Current price is: $67,312.27.

IPD Quality Pistons & Rings
IPD has a long history with aluminum pistons. From engineering to design to development and manufacturing, IPD is focused on your business success. IPDs Waukesha 7042/7044 pistons are engineered to perform. Special Ni-resist austenitic material is tightly bonded metallically to the piston body to counteract wear in the top ring groove. IPDs rings work together to improve wear resistance, provide better oil control, and reduce blow-by of exhaust gases. The top compression ring features a special tapered upper profile with lower offset barrel shape for better ring-to-sleeve wall contact.
IPD Quality Cylinder Liners
As per IPDs rigid quality standards, IPDs Cylinder Liners are engineered to precise tolerances ensuring high quality and performance. A special bainitic iron/chromium alloy material is used that includes a matrix of carbon, silicon, molybdenum, and nickel to provide tensile strength exceeding 55,000 PSI.
Category:
Includes Cylinder Kit G932200
10.5:1 Compression Ratio (4 Ring Piston)
Overhaul Engine Kit Includes
(12) Cylinder Kits (Piston with pin & locks, Piston Rings, Cylinder Liner, Liner Seals)
(12) Rod Bearings – select type above
(1) Main Bearing Set – select type above
(1) Upper Gasket Set – valve seals not included
(1) Lower Gasket Set
Waukesha used two different crankshaft types in this engine where the oil passages are drilled differently. Because of this, there are two separate main bearing styles (see diagrams below).
